Architectural Elevator Design is North America's largest manufacturer of elevator interior handrails for architectural elevator cab applications. 100% Made in the USA.

We offer 14 unique handrail styles in four different metals — Brass, Copper, Bronze, and Stainless — with custom finishes available. The Grip handrail pairs a 1.25″ square tube with a full-capture rectangular standoff that encloses all four sides of the rail — bold geometric character with maximum architectural presence.

Theme
Text Size
1
Specifications

Fixed Dimensions

Handrail Tube 1.25″ square
Standoff Body 2.89″ × 1.50″
Capture Style Full four-side wrap
Wall Offset 1.50″ past rail
End Details Grip End

The Grip handrail uses a full-capture rectangular standoff — the 1.25″ square rail passes through a fully-enclosed pocket machined from solid bar, giving the design its bold, architectural presence.

Rail length, standoff quantity, and standoff spacing are configured in Section 3 below.

Custom lengths available.

Overall lengths greater than 8′ ship LTL.

CROSS SECTION

Grip elevator handrail, interior view 1
Grip elevator handrail, interior view 2
Grip series handrail detail
2
Materials & Finishes

Select Material

Select Finish

3
Rail Configuration & Measurements

Rear Wall Handrail

Call for Custom Orders or
Assistance with your Order

Qty

Measurements

REAR WALL GRIP HANDRAIL

plan view

Side Wall Handrail

Call for Custom Orders or
Assistance with your Order

Qty

Measurements

SIDE WALL GRIP HANDRAIL

plan view

4
End Detail
5
Additional Notes / Specifications
6
Quote & Shipping Information

Quote For

Ship To

Your configuration will be downloaded as a PDF and a copy sent to our team. We'll follow up within 1 business day.
